SCL # :212781
Manufacturer Item # :MOT09188
Alternate Part # :X70671652010
1-3/4 HP, Volts: 208-230, Hertz: 50-60, Phase: 1, Amps: 4.6-4.3, Rpm/Speed: 1125-950/2, Motor Type:
PSC, Frame: 48, Bearing: Ball, Body: Totally Enclosed, Duty: Continuous, Rotation: CCW Lead End, Shaft: 3-1/4" Keyed, Motor Length Less Shaft: 6-1/2", Overall Length: 9-3/4", Motor Diameter:
5-3/4", Mounting: Belly Band, Weight: 20Lbs, In Mfg. Box, Made In Mexico
PSC, Frame: 48, Bearing: Ball, Body: Totally Enclosed, Duty: Continuous, Rotation: CCW Lead End, Shaft: 3-1/4" Keyed, Motor Length Less Shaft: 6-1/2", Overall Length: 9-3/4", Motor Diameter:
5-3/4", Mounting: Belly Band, Weight: 20Lbs, In Mfg. Box, Made In Mexico
Product Details
Product Details
SCL # :212781
Manufacturer Item # :MOT09188
Alternate Part # :X70671652010
1-3/4 HP, Volts: 208-230, Hertz: 50-60, Phase: 1, Amps: 4.6-4.3, Rpm/Speed: 1125-950/2, Motor Type:
PSC, Frame: 48, Bearing: Ball, Body: Totally Enclosed, Duty: Continuous, Rotation: CCW Lead End, Shaft: 3-1/4" Keyed, Motor Length Less Shaft: 6-1/2", Overall Length: 9-3/4", Motor Diameter:
5-3/4", Mounting: Belly Band, Weight: 20Lbs, In Mfg. Box, Made In Mexico
PSC, Frame: 48, Bearing: Ball, Body: Totally Enclosed, Duty: Continuous, Rotation: CCW Lead End, Shaft: 3-1/4" Keyed, Motor Length Less Shaft: 6-1/2", Overall Length: 9-3/4", Motor Diameter:
5-3/4", Mounting: Belly Band, Weight: 20Lbs, In Mfg. Box, Made In Mexico
Specifications
Specifications
Cabinet Size:6
Circuit Phase:1
Circuit Voltage:208-230
Maximum Hertz:50-60
Packaging:Manufacture packaging
