SCL # :223214
Manufacturer Item # :RH1PZ3617STANNJ
3 Ton AC/HP Air Handler, Airflow: Multiposition, Volts: 208-240, Hertz: 60, Phase: 1, CFM: 1248, Refrigerant: R-410A, Motor Type: PSC, Metering Device: TXV, Connection Size: Suction-3/4", Liquid-3/8", Type: Air Source, Dimensions: 42-1/2''H X 17-1/2''W X 21-11/16''D, Weight: 90 lbs ***Compatible Heat Kits: RXBH-17?03J-1, RXBH-1724?(03-10)J-1, RXBH-1724A(13-18)J-1 (not included)***
Product Details
Product Details
SCL # :223214
Manufacturer Item # :RH1PZ3617STANNJ
3 Ton AC/HP Air Handler, Airflow: Multiposition, Volts: 208-240, Hertz: 60, Phase: 1, CFM: 1248, Refrigerant: R-410A, Motor Type: PSC, Metering Device: TXV, Connection Size: Suction-3/4", Liquid-3/8", Type: Air Source, Dimensions: 42-1/2''H X 17-1/2''W X 21-11/16''D, Weight: 90 lbs ***Compatible Heat Kits: RXBH-17?03J-1, RXBH-1724?(03-10)J-1, RXBH-1724A(13-18)J-1 (not included)***
Specifications
Specifications
Cabinet Size:17.5
Capacity:3
Circuit Phase:1
Circuit Voltage:208/240
Maximum Hertz:60
Packaging:Manufacture packaging
System Controls:NON-COMMUNICATING
