SCL # :219691
Manufacturer Item # :RHP15060B21S/A4AH5V60A1C30A
Alternate Part # :218094,219611
5 ton split-system heat pump; Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Refrigerant: R410A, Department of Energy Guide SEER2: 15.2, Stage: two, Connections: 3/8" x 7/8" sweat, Factory Charge: 9 lbs 10 oz, Type: air, Dimensions: 46"H x 38"W x 34-1/4"D, Weight: 242 lbs
paired with:
5 ton AC/HP air handler; Airflow: multi-position, Volts: 208-230, Hertz: 60, Phase: 1, CFM: 1800, Refrigerant: R-410A, Motor Type: ECM, Metering Device: TXV, Connection Size: suction- 7/8", liquid- 3/8", Type: air source, Dimensions: 57-2/5"H x 23-1/2"W x 21-1/8"D, Weight: 174 lbs
***COMPATIBLE HEAT KIT IS NOT INCLUDED (Model#s BAYHTR15(04-25)BRK, BAYHTR15(04-10)LUG, and BAYHTR35(10-17)LUG***
paired with:
5 ton AC/HP air handler; Airflow: multi-position, Volts: 208-230, Hertz: 60, Phase: 1, CFM: 1800, Refrigerant: R-410A, Motor Type: ECM, Metering Device: TXV, Connection Size: suction- 7/8", liquid- 3/8", Type: air source, Dimensions: 57-2/5"H x 23-1/2"W x 21-1/8"D, Weight: 174 lbs
***COMPATIBLE HEAT KIT IS NOT INCLUDED (Model#s BAYHTR15(04-25)BRK, BAYHTR15(04-10)LUG, and BAYHTR35(10-17)LUG***
Product Details
Product Details
SCL # :219691
Manufacturer Item # :RHP15060B21S/A4AH5V60A1C30A
Alternate Part # :218094,219611
5 ton split-system heat pump; Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Refrigerant: R410A, Department of Energy Guide SEER2: 15.2, Stage: two, Connections: 3/8" x 7/8" sweat, Factory Charge: 9 lbs 10 oz, Type: air, Dimensions: 46"H x 38"W x 34-1/4"D, Weight: 242 lbs
paired with:
5 ton AC/HP air handler; Airflow: multi-position, Volts: 208-230, Hertz: 60, Phase: 1, CFM: 1800, Refrigerant: R-410A, Motor Type: ECM, Metering Device: TXV, Connection Size: suction- 7/8", liquid- 3/8", Type: air source, Dimensions: 57-2/5"H x 23-1/2"W x 21-1/8"D, Weight: 174 lbs
***COMPATIBLE HEAT KIT IS NOT INCLUDED (Model#s BAYHTR15(04-25)BRK, BAYHTR15(04-10)LUG, and BAYHTR35(10-17)LUG***
paired with:
5 ton AC/HP air handler; Airflow: multi-position, Volts: 208-230, Hertz: 60, Phase: 1, CFM: 1800, Refrigerant: R-410A, Motor Type: ECM, Metering Device: TXV, Connection Size: suction- 7/8", liquid- 3/8", Type: air source, Dimensions: 57-2/5"H x 23-1/2"W x 21-1/8"D, Weight: 174 lbs
***COMPATIBLE HEAT KIT IS NOT INCLUDED (Model#s BAYHTR15(04-25)BRK, BAYHTR15(04-10)LUG, and BAYHTR35(10-17)LUG***
Specifications
Specifications
Cabinet Size:38
Capacity:5
Circuit Phase:1
Circuit Voltage:208-230
Maximum Hertz:60
Packaging:Manufacture packaging
Stage:2
System Controls:NON-COMMUNICATING
