Product Details
Product Details
SCL # :186914
Manufacturer Item # :44YU11
Item: Agricultural Exhaust Fan, Type: Slant-Wall, Belt-Drive, Propeller Dia. (In.): 54, Fan RPM:
573, Voltage: 115/230, Hertz: 60, Phase: 1, Full Load Amps: 8.6/4.3, HP: 1, Motor RPM: 1725, Motor Type: Capacitor Start, Capacitor Run, Motor Enclosure: Teao, Motor Insulation Class: B, Height (In.): 58-5/8, Width (In.): 58-5/8, Max. Depth (In.): 34, Opening Required H (In.): 62-1/2 , Opening Required W (In.): 59-1/2, Flange Width (In.): 2, Venturi Clearance Dia. (In.): 5/16, Venturi Depth (In.): 4-1/2, Mounting Location: Wall, Max. Ambient Temp. (F): 104, Shaft Dia.
(In.): 1, Bearing Type: Sealed Ball, Number Of Blades: 3, Propeller Material: Galvanized Steel, Frame Material: Galvanized Steel, Frame Finish: Galvanized Steel, Mesh Size: 1 X 2,Origin:USA
573, Voltage: 115/230, Hertz: 60, Phase: 1, Full Load Amps: 8.6/4.3, HP: 1, Motor RPM: 1725, Motor Type: Capacitor Start, Capacitor Run, Motor Enclosure: Teao, Motor Insulation Class: B, Height (In.): 58-5/8, Width (In.): 58-5/8, Max. Depth (In.): 34, Opening Required H (In.): 62-1/2 , Opening Required W (In.): 59-1/2, Flange Width (In.): 2, Venturi Clearance Dia. (In.): 5/16, Venturi Depth (In.): 4-1/2, Mounting Location: Wall, Max. Ambient Temp. (F): 104, Shaft Dia.
(In.): 1, Bearing Type: Sealed Ball, Number Of Blades: 3, Propeller Material: Galvanized Steel, Frame Material: Galvanized Steel, Frame Finish: Galvanized Steel, Mesh Size: 1 X 2,Origin:USA
Specifications
Specifications
Cabinet Size:40
