Número de serie:M000185
Número de artículo del fabricante:GUH80C045A3M/DX4SEA1810/TH6320ZW2003/U
Pieza alternativa n.°:215204,220462,219757
44,000 BTU Upflow/Horizontal Gas Furnace, Efficiency: 80, Volts: 120, Hertz: 60, Phase: 1, Cfm:
1200, Stage: Single, Speed: Variable, Motor Type: Ecm, BTU Input: 44,000, BTU Output: 35,200, Dimensions: 33"H X 14-1/2"W X 28-3/8"D, Weight: 111 Lbs, Plenum Opening Dimensions: 19-1/2" X 13-3/8", In Mfg. Box, Made In Mexico **Propane Conversion Kit: 11K50, 11K45 (Not Included)** No MFG Badge Paired with:
1.5 Ton Single Stage Split-System Air Conditioner, Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Department of Energy Guide SEER2: 14.3, Stage: Single, Refrigerant: R410A, Connection Size:
3/8"X3/4", Connection Type: Sweat, Factory Charge: 64 oz, Type: Air, Dimensions: 27''H x 26''W x 26''D, Weight: 126 lbs ***Unit includes a Manufacture Warranty, register your unit with the Manufacturer for details*** Paired with:
Programmable Digital Touch Screen Thermostat, 2-Heat/2-Cool Conventional, 3-Heat/2-Cool Heat Pump, Temperature Range: 40°F to 90°F (Heating) and 50°F to 99°F (Cooling), Power: Hardwired, Battery, Color: White, Applications: Heat Pumps, Conventional system, Dimensions: 4-1/16''H X 4-1/16''W X 1-5/32''D
1200, Stage: Single, Speed: Variable, Motor Type: Ecm, BTU Input: 44,000, BTU Output: 35,200, Dimensions: 33"H X 14-1/2"W X 28-3/8"D, Weight: 111 Lbs, Plenum Opening Dimensions: 19-1/2" X 13-3/8", In Mfg. Box, Made In Mexico **Propane Conversion Kit: 11K50, 11K45 (Not Included)** No MFG Badge Paired with:
1.5 Ton Single Stage Split-System Air Conditioner, Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Department of Energy Guide SEER2: 14.3, Stage: Single, Refrigerant: R410A, Connection Size:
3/8"X3/4", Connection Type: Sweat, Factory Charge: 64 oz, Type: Air, Dimensions: 27''H x 26''W x 26''D, Weight: 126 lbs ***Unit includes a Manufacture Warranty, register your unit with the Manufacturer for details*** Paired with:
Programmable Digital Touch Screen Thermostat, 2-Heat/2-Cool Conventional, 3-Heat/2-Cool Heat Pump, Temperature Range: 40°F to 90°F (Heating) and 50°F to 99°F (Cooling), Power: Hardwired, Battery, Color: White, Applications: Heat Pumps, Conventional system, Dimensions: 4-1/16''H X 4-1/16''W X 1-5/32''D
Product Details
Product Details
Número de serie:M000185
Número de artículo del fabricante:GUH80C045A3M/DX4SEA1810/TH6320ZW2003/U
Pieza alternativa n.°:215204,220462,219757
44,000 BTU Upflow/Horizontal Gas Furnace, Efficiency: 80, Volts: 120, Hertz: 60, Phase: 1, Cfm:
1200, Stage: Single, Speed: Variable, Motor Type: Ecm, BTU Input: 44,000, BTU Output: 35,200, Dimensions: 33"H X 14-1/2"W X 28-3/8"D, Weight: 111 Lbs, Plenum Opening Dimensions: 19-1/2" X 13-3/8", In Mfg. Box, Made In Mexico **Propane Conversion Kit: 11K50, 11K45 (Not Included)** No MFG Badge Paired with:
1.5 Ton Single Stage Split-System Air Conditioner, Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Department of Energy Guide SEER2: 14.3, Stage: Single, Refrigerant: R410A, Connection Size:
3/8"X3/4", Connection Type: Sweat, Factory Charge: 64 oz, Type: Air, Dimensions: 27''H x 26''W x 26''D, Weight: 126 lbs ***Unit includes a Manufacture Warranty, register your unit with the Manufacturer for details*** Paired with:
Programmable Digital Touch Screen Thermostat, 2-Heat/2-Cool Conventional, 3-Heat/2-Cool Heat Pump, Temperature Range: 40°F to 90°F (Heating) and 50°F to 99°F (Cooling), Power: Hardwired, Battery, Color: White, Applications: Heat Pumps, Conventional system, Dimensions: 4-1/16''H X 4-1/16''W X 1-5/32''D
1200, Stage: Single, Speed: Variable, Motor Type: Ecm, BTU Input: 44,000, BTU Output: 35,200, Dimensions: 33"H X 14-1/2"W X 28-3/8"D, Weight: 111 Lbs, Plenum Opening Dimensions: 19-1/2" X 13-3/8", In Mfg. Box, Made In Mexico **Propane Conversion Kit: 11K50, 11K45 (Not Included)** No MFG Badge Paired with:
1.5 Ton Single Stage Split-System Air Conditioner, Circuit Voltage: 208-230, Hertz: 60, Phase: 1, Department of Energy Guide SEER2: 14.3, Stage: Single, Refrigerant: R410A, Connection Size:
3/8"X3/4", Connection Type: Sweat, Factory Charge: 64 oz, Type: Air, Dimensions: 27''H x 26''W x 26''D, Weight: 126 lbs ***Unit includes a Manufacture Warranty, register your unit with the Manufacturer for details*** Paired with:
Programmable Digital Touch Screen Thermostat, 2-Heat/2-Cool Conventional, 3-Heat/2-Cool Heat Pump, Temperature Range: 40°F to 90°F (Heating) and 50°F to 99°F (Cooling), Power: Hardwired, Battery, Color: White, Applications: Heat Pumps, Conventional system, Dimensions: 4-1/16''H X 4-1/16''W X 1-5/32''D
Specifications
Specifications
Tamaño del gabinete:14.5
Eficiencia:80%
Embalaje:Manufacture packaging
Escenario:1
Controles del sistema:NON-COMMUNICATING
Tipo:GAS/PROPANE
